[ZABBIX] Zabbix-docker Server Installed - woodev.co

Create Docker Network "zabbix-net"

docker network create --subnet 172.20.0.0/16 --ip-range 172.20.240.0/20 zabbix-net



Run Docker Container "mysql-server"

docker run --name mysql-server -t -e MYSQL_DATABASE="zabbix" -e MYSQL_USER="zabbix" -e MYSQL_PASSWORD="zabbix1004" -e MYSQL_ROOT_PASSWORD="zabbix1004" --network=zabbix-net --restart unless-stopped -d mysql:8.0-oracle --character-set-server=utf8 --collation-server=utf8_bin --default-authentication-plugin=mysql_native_password





Run Docker Container "zabbix-java-gateway"

docker run --name zabbix-java-gateway -t --network=zabbix-net --restart unless-stopped -d zabbix/zabbix-java-gateway:alpine-6.4-latest



Run Docker Container "zabbix-server-mysql"

docker run --name zabbix-server-mysql -t -e DB_SERVER_HOST="mysql-server" -e MYSQL_DATABASE="zabbix" -e MYSQL_USER="zabbix" -e MYSQL_PASSWORD="zabbix1004" -e MYSQL_ROOT_PASSWORD="zabbix1004" -e ZBX_JAVAGATEWAY="zabbix-java-gateway" --network=zabbix-net -p 10051:10051 --restart unless-stopped -d zabbix/zabbix-server-mysql:alpine-6.4-latest



Run Docker Container "zabbix-web-nginx-mysql"

docker run --name zabbix-web-nginx-mysql -t -e ZBX_SERVER_HOST="zabbix-server-mysql" -e DB_SERVER_HOST="mysql-server" -e MYSQL_DATABASE="zabbix" -e MYSQL_USER="zabbix" -e MYSQL_PASSWORD="zabbix1004" -e MYSQL_ROOT_PASSWORD="zabbix1004" --network=zabbix-net -p 81:8080 --restartnless-stopped -d zabbix/zabbix-web-nginx-mysql:alpine-6.4-latest



Run Docker Container "zabbix-agent"

docker run --name zabbix-agent --network=zabbix-net --link mysql-server:mysql --link zabbix-server-mysql:zabbix-server -e ZBX_HOSTNAME="Zabbix server" -e ZBX_SERVER_HOST="zabbix-server-mysql" -d zabbix/zabbix-agent -p 10050:10050



Run Docker Container "zabbix-agent"

해당 명령어 수행 시, 출력된 IP를 복사

docker inspect zabbix-agent | grep "IPAddress\": "





Edit Zabbix Dashboard

Interfaces > Add > Zabbix Agent > "복사한 IP 붙여넣기" > Update
